Many customers use the Innova-Switch to confirm that they have flow to their analyzers from the sample systems to ensure the analyzers are receiving a representative sample of what is in the process line. If the flow to an analyzer is interrupted, then the analyzer is sending data to the control system that is not likely to be representative of what is actually in the process lines. This can cause many problems: you could be manufacturing off spec product, you could be making chemical additions that could cause damage to equipment or people, emissions may be out of range possibly resulting in serious fines, just to name a few.
Often our customers want to notify others when a safety shower or eyewash station is activated. It may be extremely important to get someone to the location to assist the individual. In addition, because of the immediate danger posed to the individuals well being he/she may not have been able to take the steps necessary to prevent an even large spill or hazardous condition. Notifying others of the problem may prevent additional injuries and reduce or prevent fines because of a spill.
Customers monitor the flow of heat transfer fluids such as Dow-Therm with Innova switches. The high temperature makes this application extremely difficult for other technologies. The Innova switch high temperature version is at home in harsh environments such as this. Our level switches are also used to monitor the fluid level in Dow-Therm boilers thus preventing burnout.
Because of the reliability and durability of Innova switches they are ideal for these applications whether for gas or liquid service. Frequently a switch is mounted just over a rupture disk or pressure relief valve. By doing this the switch will alarm on the slightest leak notifying everyone in many cases before a full release occurs. When working with liquids it is often best to set it up as a level switch, this allows the switch to indicate a leak as soon as the liquid comes in contact with the sensor. In gas applications, it is often best to use a flow switch. With the Innova switches capability to indicate gas flows all the way down to .1 feet per second, the smallest leak may be detected | |
 |
Unique Product Features |
| • Mass flow Switch for the detection of the mass flow rate of liquids and gases • Range of 0.01 to 5 fps in liquids and 0.1 to 500 fps gases • Fast response time of 0.5 to 10 seconds (media dependent) • Wide operating temperature range of -100F to +390F (-70C to 200C) • Operating Pressure: to 3000 psia (207 bar) • CE, CENELEC and CSA approval • Repeatability: +/- 1% of set point (Flow) or 1/32" (0.8mm) Level • Stability: Drift <0.5% from calibrated set point over a range of +/-50F • Temperature compensated through entire range • Enclosure: Explosion Proof; NEMA 3, 4X, 7, 9. CSA, FM, UL, CENELEC and EECS approved • Process Connection: 0.75" MNPT standard. 0.5" and larger MNPT and various other process connections such as sanitary and flanges optional • Insertion Length: 2.0" standard. 0.5" or greater optional • Input Power: 115 VAC, 50/60Hz standard. 230 VAC, 50/60Hz optional, 24VDC optional. 3.1 Watt maximum • Output: 5A. 250 VAC. DPDT with fail safe capability |
|
