Top-Trak® Model 822/824 Mass Flow Meters

Economical Analog Mass Flow Meters

Our Top-Trak® MFM directly measures the mass flow rate of gases in flow ranges from 0-10 sccm up to 0-50 slpm. The Model 822 and Model 824 are for measurement of air and ALL inert gases & mixtures.  Both models serve a wide range of inert gas flow applications including process control, flow research, instrument OEMs, gas panels, and cell culture maintenance.

In addition, both models offer standard 0-5 VDC or 4-20mA output signals. Our Model 822 is equipped with a large tiltable LCD readout available in your choice of engineering units.  The LCD readout can be mounted on the instrument or on a remote panel. Our Model 824 is a compact OEM configuration that comes without the LCD readout. Sierra’s Platinum Sensor Technology to eliminate zero-drift and create excellent long-term reliability is utilized in the design of both Models.

» Mass Flow Meter Selection Chart







Product OverviewDownloadsApplication StoriesImages & Video
Unique Product Features
• Accuracy of +/- 1.5% of full scale
• Direct monitoring of mass flow rate
• Flow ranges from 0-10 sccm to 0-50 slpm
• Large tiltable LCD readout
• Use with ALL inert gases & mixtures
• “Primary Standard” calibration for best accuracy & NIST traceability
• CE approved
